Side Airbag Satellite Sensor

Check for damaged components and look for broken bent.

Side airbag satellite sensor.

Ocs system passenger weight sensor calibration b00d5. Left front side air bag satellite sensor harness is open or shorted left front side air bag satellite sensor circuit poor electrical connection how is the b0091 code repair. Replace the rear side air bag satellite sensor if it has been dropped or sustained an impact. The sensor data are processed by the central airbag ecu which activates adequate restraint systems according to the classification and severity of the accident.

Do not strike the rear side air bag satellite sensor. The sensors can be installed in the ecu or as satellite sensors in the periphery of the vehicle front side and rear. The satellite sensor is an integrated type of the g. Front door satellite sensor rh.

Front side air bag satellite sensor rh. When the air bag diagnosis sensor unit acu define the both signal voltage of the g sensor and the safing sensor to be that of the collision which exceeds the specified level the driving circuit switches on and feeds the electric ignitor of both the side air bag and curtain air bag. Passenger airbag off indicator lamp. Position the rear side air bag satellite sensor using the pawl before tightening the bolt to specification.

The front door satellite sensor rh is wired to the air bag diagnosis sensor unit. Installation installation is in the reverse order of removal. Another type of airbag sensor has a micro accelerometer chip that sends an electronic signal to the airbag when the vehicle is impacted hard enough. Rear side airbag satellite sensor rh passenger.

The air bag diagnosis sensor unit will monitor the front door satellite sensor rh for internal failures and its circuits for communication errors. There are several types of airbag sensors such as the spring and mass type which works using a weight held by a spring and trips to close a switch once an impact occurs.
